ELECTRICAL PANEL BOARDS

METERING PANELS

We manufacture and supply metering panels for individual houses, apartments & gated communities in a wide range, which are capable of minimizing space consumption. using high-quality FLRS wires, MCBs, and incoming mccb makes us reliable to the customer. And also, we have a large customer base of metering panels not only from Hyderabad, but also, we are well known in all the districts of Telangana, Andhra Pradesh, and a few districts of Karnataka.

PCC PANELS

We manufacture and supply pcc panels, which are used for diverse industrial
applications. These are used to supervise and control the voltage and reactive
power of the power system. These panels are made of quality raw material and are
extremely sturdy in construction.

Main LT panel / PCC with single / Multiple Incomers, bus couplers, with proper interlocking.
Required protections, Fault indications, interlocking are provided.
Various designs are offered in PCC like top / middle / bottom horizontal bus chambers, panel with Aluminum / Copper bus bars, top / bottom / front / rear cable termination, combinations of APFC part with PCC.
Required facilities like DG incomer with AMF functions, Cut-Off of non essen tial feeders at the event of failure of mains power.
Panel with provision to connect bus duct at main incomer side.

M.C.C PANELS

We offer MCC Panels that are designed for the distribution of
power, main incoming and motor control panels. These MCC Panels
are designed with utmost care and stringent quality inspection to
ensure client satisfaction. This range is available in standard as well as
in customized size.

Fix / Draw out Type MCC.
Motor control center with DOL / RDOL / SD starters.
Various designs provided like single / Double Front, Fixed / Draw out type, with DCS / Marshaling terminations.
Required control voltage facilities with control transformer, con trol bus.
All starters are provided with type 2 co-ordinations where required.

DRAWOUT PANELS

In every modern industry, reliable electrical systems are a must to reduce production downtime & improve efficiency. The customer will opt for a drawout panel. Panel is designed to provide fool-proof control for the motors that are installed in many process industries, viz. fertilizer, petrochemical, cement, oil refineries, chemical plants, steel plants, power stations, material handling plants & other continuous process plants, wherein the continuous flow of power without the
slighest break is a must.

Backed by in-depth industry knowledge, we have earned domain expertise in developing an optimum quality MCC Panel. The drawout MCC panel offered by us is made up of superior quality parts. These are manufactured under the close supervision of our expert professionals, who have rich industry experience respective domains

SYNCHRONISING/ AMF PANELS

We manufacture and supply a fully automatic synchronizing panels operated
by microprocessor based relays qualitative range of panels.

AMF , Auto synchronizing, Manual synchronizing, Auto load sharing, Active & Reactive power management with protection such as U/ V, O/ V, E/F, O/C IDMT, reverse power etc.
Load unbalance metering such as Ammeter, Voltmeter, Hz meter, K W, PF, K W H, Double Volt, Double Hz, Synchroscope.
Team of experts to provide commencing / site services.

BUSDUCTS

Bus duct is used for the effective and efficient supply of electricity in mostly
industrial locations. Copper or aluminium is used for the conductor of bus duct
that be insulated and enclosed completely for protection against mechanical
damage and dust accumulation.

A bus duct system is an effective method of distributing power to your switch-
gear and various loads. However, bus duct problems can lead to catastrophic
damage and extensive downtime.

Allow for the space requirements and weight of the bus duct. You may need to
change other components or select a different style of bus duct for your installation. If you are installing bus duct outside, select a housing type that sheds rainwater rather than pooling it on top of the housing.

Bus ducts generally used for transformers having a capacity of 630kva to
4mva .

VFD PANELS

Electrical VFD control panels are designed to control the speed of electric
motor and feed pump. They are widely used in drilling, pumping, and other large machine applications. The VFD panels are widely used in tube mills, paper mills, extruder plants, rolling Mills, the cable industry, and CTL Lines. They are even installed in hospitals, business houses, and other public places. VFD control panels are designed to match the variable speed requirements of a process unit, and so are vigorously tested on various speed parameters

We are manufacturing and supplying a diverse range of VFDs, which are
designed according to international standards. Our VFD Panels are available in various dimensions and standard sizes as per the client’s specifications. Apart from this, we are offering VFD Panels of various specifications that are effectively used in various industrial applications. Also, we have strong tie-ups with the world’s well-known and reliable VFD Panel brand manufacturers. Some of the features of

Our VFD panels are:

APFC PANELS

We manufacture and supply a qualitative range of panels. These APFCs are
designed and developed using advanced techniques and are capable of saving maximum power and energy. These APFC Panels are highly efficient and accurately monitor the reactive power in power systems for saving energy, and can alter the
system voltage as well as current

L.T PANELS

Our vast range comprises LT Panels that are manufactured using high-quality
quality electrical components like ACB, MCCB, SFU, and Protection Relay with Aluminum & Copper Busbar as per the requirements of the clients, consultants’ specifications. That will be a huge Application in Industries, big commercial complexes. These LT panels are designed in such a manner that installed in a substation to enable proper Power Distribution, selective fault protection & contact isolation capabilities. LT panels are designed in such a manner that Single/multiple incomers, bus couplers with proper interlocking to enable power distribution, selective fault protection & selective. Fault Level will be maintained with Transformer Specifications.

OUTDOOR FEEDER PILLAR PANEL

We manufacture and supply outdoor feeder pillar panels to ventures, gated community villas, and venture plots where underground cabling along with feeder pillar Panels made compulsory in the HMDA region.

TRANSFORMER LAISON WORKS

We also take up turnkey of transformer laison works of apartments,
commercial buildings & industries. We completed many projects in and around Hyderabad.
